July 5, 2013

Features of Meridiani Planum
Features of Meridiani Planum

Credits: NASA/JPL/University of Arizona - Credits for the additional process. and color.: Dr Paolo C. Fienga/Lunar Explorer Italia/IPF

In this frame, taken by the NASA - Mars Reconnaissance Orbiter on the date of June, 1st, 2013, we can see a few interesting (although very common) Surface Features which characterize the Meridiani Planum Region of Mars. In particular, we can see an old and (still) Unnamed Impact Crater - with the "usual" Dunefield on its Floor - that is located on the very upper portion of the frame and just below a (relatively) Sand-free section of Surface known as "Martian Paving". Afterwards, moving down towards the South (such as towards the lower portion of the frame), we can find an area where there are many Sand Ripples and a few small Impact Craters. Finally, on the very lowest portion of the picture, we can also see more Sand Ripples, a number of Sand Dunes, several very small Impact Craters and quite a few Rocky Outcrops.


However, the Martian Surface pictured here, in our opinion (as IPF), and contrary to the common idea of how the Meridiani Planum Region of Mars is - generally - characterized and known (such as an almost totally plain and reliefs-free Region), is really far from being flat at all: as a matter of fact, if you observe the picture carefully, you will be able to notice that the whole area which has been photographed by the NASA - Mars Reconnaissance Orbiter (and, particularly, the area visible in the central and lower portion of the frame - meaning the one located to the South of the main visible Feature, such as the Unnamed Impact Crater) appears to show several points of Subsidence, a few Ridges and some (most likely very short and small) Hillocks.


Mars Local Time: 14:09 (Early Afternoon)
Coord. (centered): 1,584° South Lat. and 3,132° East Long.
Spacecraft altitude: 268,9 Km (such as about 166,986 miles)
Original image scale range: 26,9 cm/pixel (with 1 x 1 binning) so objects ~ 81 cm across are resolved
Map projected scale: 25 cm/pixel
Map projection: EQUIRECTANGULAR
Emission Angle: 0,0°
Phase Angle: 34,0°
Solar Incidence Angle: 34° (meaning that the Sun was about 56° above the Local Horizon at the time the picture was taken)
Solar Longitude: 328,5° (Northern Winter - Southern Summer)
Credits: NASA/JPL/University of Arizona
Additional process. and coloring: Lunar Explorer Italia


This picturee (which is a NASA - Original Mars Reconnaissance Orbiter NON-Map Projected b/w frame identified by the serial n. ESP_032098_1785) has been additionally processed and then colorized in Absolute Natural Colors (such as the colors that a human eye would actually perceive if someone were onboard the NASA - Mars Reconnaissance Orbiter and then looked down, towards the Surface of Mars), by using an original technique created - and, in time, dramatically improved - by the Lunar Explorer Italia Team.
