Unnamed Pedestal Crater (CTX Frame)
Unnamed Pedestal Crater (CTX Frame)

Credits: NASA/JPL/University of Arizona - Credits for the additional process. and color.: Dr Paolo C. Fienga/LXTT/IPF

This HiRISE image, taken by the NASA - Mars Reconnaissance Orbiter on June, 4, 2014, shows us what is commonly known as a "Impact Crater with Pedestal" (in this case, an "Unnamed" one), and this defnition comes from the fact that the Level of the Surface adjacent to the Impact Crater itself is elevated (---> raised) in relation (---> as) to the Surface of Surrounding Terrain. The Raised Surface shows patterns and a general outline resembling what Ejecta would look like after being thrown out from the Crater during (and by) the Impact Event.

In fact, this specific Impact probably occurred at a time when the Surface of the whole scene was at the Level of the (now) Raised Surface. The Ejecta landed on the part of this Surface which is close to the Crater, then the occurrence of several Erosional Phoenomena removed more Material from the rest of the scene while the Impact Ejecta - somehow - "shielded" the area around the Impact Crater, protecting the Ground under it from further erosion and kept it at an higher Level.

The Eroded - or "missing", if you want - Terrain in the rest of the area, NASA's Planetary Scientists said, might have also contained (Water) Ice. The presence of Lobe shapes at the base of the Raised Ejecta and Polygons (only visible when zoomed in) on the Surface, in fact, both suggest that the Material forming the Pedestal may have contained (or may still contain) Water Ice (but we, as IPF, seriously doubt this - truly unsupported, in our humble opinion - assumption).

Last, but not least, the Pattern of the Ejecta is asymmetric around the Impact Crater, thus suggesting that the Impactor could and should have hit the Ground traveling from the North/East and following a - remarkably - Oblique Angle as to the hit Surface.

Mars Local Time: 15:19 (Early Afternoon)
Coord. (centered): 52,496° North Lat. and 93,277° East Long.
Spacecraft altitude: 305,4 Km (such as about 189,655 miles)
Original image scale range: 30,6 cm/pixel (with 1 x 1 binningso objects ~ 61,1 cm across are resolved (with 2 x 2 binning)
Map projected scale: 25 cm/pixel
Emission Angle: 2,9°
Phase Angle: 56,6°
Solar Incidence Angle: 54° (meaning that the Sun was about 36° above the Local Horizon at the time the picture was taken)
Solar Longitude: 140,6° (Northern Summer - Southern Winter)
Credits: NASA/JPL/University of Arizona
Additional process. and coloring: Lunar Explorer Italia

This picture (which is a NASA - Original Mars Reconnaissance Orbiter b/w and Map-Projected frame identified by the serial n. ESP_036815_2330) has been additionally processed, magnified to aid the visibility of the details, contrast enhanced, Gamma corrected, and then colorized in Absolute Natural Colors (such as the colors that a human eye would actually perceive if someone were onboard the NASA - Mars Reconnaissance Orbiter and then looked down, towards the Surface of Mars), by using an original technique created - and, in time, dramatically improved - by the Lunar Explorer Italia Team.
